[Specification]
Inputs – (2) 3-pin Female XLR plus(2) 3-pin male XLR links
Input Impedance – 20k ohms, actively balanced
Input Cmrr – >90dB
Outputs – (2) 4-pole Speakon
Output Power(RMS per channel) – 1200 watts into 8 Ohms @ 1kHz
2250 watts into 4 ohms @ 1kHz
3200 watts into 2 ohms @ 1kHz, 4500 watts peak
Thd@Rated Power – <0.008% @ 1kHz, 4ohms
Hum and Noise – -105dB
Gain – +35.75dB
Sensitivity – +6dBu for rated output
Damping Factor – 400(1kHz, 8 ohms)
Frequency Response – 20Hz ~ 20kHz, +0/-0,5dB
