[Specification]

Total # Of Inputs 16
Microphone Inputs 8 Mono, 4 Stereo, XLR-F Connectors
1 x Talkback Mic Input, XLR-F
Line Inputs 8 Mono, 4 Stereo, TRS Connectors
1 x Stereo Playback Input, RCA
Matrix Type 7 x 2, XLR-M
AUX Returns 2 x Stereo, TRS
Bus 6 x Aux Mix Busses, XLR-M
BUS (Group) Outputs 4 x Audio Subgroups, XLR-M
Master Output 1 x Stereo Master, XLR-M
1 x Mono Master, XLR-M
FireWire 16 x 16 Channel, FireWire 400 (6-Pin)
EQ Section 4-Band Swept EQ
Phantom Power 48 V
Dimensions (WxDxH) 19.0 x 9.65 x 22.77″ (482.6 x 245.1 x 578.36 mm) (13RU)
Weight 51.8 lb (23.5 kg)
