Interpreter Booth

[Specification]

– for no more than two interpreters 1,60 m – for two or three interpreters 2,40 m – for three or four interpreters 3,20 m
b) depth: 1,60 m
c) height: 2,00 m
NOTE In very exception circumstances, where space restrictions and internal transport problems are such that the standard dimensions cannot be used, dimensions of 1,50 x 1,50 x 1,90 m may be used for no more than two interpreters





Delegation (analog)-JSM-240C

[Specification]

– Built-in stand speaker
– Reset features for chairman microphone
When pressed the button causes all currently active delegate microphones to be temporarily or permanently muted.
– Microphone has ‘on’ indicator (red LED)
– Built-in AGC circuit to control overloaded input and output level
– Digital howling suppression
– Including connectors to attach the each units
– Detachable Gooseneck microphone
– Connects up to 50 microphone units ( Left- 25 SET / Right? 25 SET )



CANON-LBP9104Cdn

[Specification]

Color print speed 20 pages / black-and-white 20-sheet
Resolution 9600dpi equivalent
Black-and-white first page print speed color 13.3 seconds / 10.5 seconds
Two-sided printing the default
Memory 32MB
Wait time 37 seconds or less
Emulation CAPT
On Demand settlers settled way way
X 1, default 250-sheet Paper Feed Method
Multi-Tray 100-sheet
Optional 500-sheet x3 only
Medium capacity of 250 sheets
Corresponding paper size cassette A3, B4, A4, B5, A5, 12 x 18, Ledger (11 x 17), Legal, Letter,
Executive, 8K, 16K, Envelope DL, Envelope COM10, Envelope C5,
Envelope B5, Envelope Monarch, Custom Size Paper (see the documentation)
Multi-Tray A3, B4, A4, B5, A5, 12 x 18, Ledger (11 x 17), Legal, Letter,
Executive, 8K, 16K, Envelope DL, Envelope COM10, Envelope C5,
Envelope B5, Envelope Monarch, Custom Size Paper (see the documentation)
Process (CPU) 192Mhz
Corresponding OS Windows 2000 / XP / VISTA / 7 / Server2003 / Server2008
Interface USB 2.0 Hi-Speed, 100Base-TX/10Base-T
Noise, atmospheric, ambient noise level of silent / Actions when 50.6dB (A) or less

HP p1606dn

[Specification]

250-sheet input tray
Automatic Duplex Printing
Hi-Speed USB 2.0 port, 10/100 Ethernet networking (Cat 5 twisted pair cable required)
4 LED indicator lights, 2 buttons
150-sheet face-down bin, Up to 150 sheets output tray
Use only Original HP Toner in your HP printer for great results, print after print



Jimmy Jib

[Specification] Camera height from below ground level to 12 metres in one continuous move.
Arm length from 2 metres (6’6”) to 12 metres (40’)
Takes any broadcast camera
Tracking on wheels or rails
Suitable for studio, OB or location shooting
Battery or mains power
As little as 1 hour set-up time
Remote pan & tilt head can be used separately on scaffold mount or stand


XDCAMHD

[Specification]
From our experience with previous versions of XDCAM systems, we were confident that the technology had the right combination of features, quality and performance,” said David Mazza, senior vice president, engineering, NBC Olympics. “These new models actually improve our picture quality and reduce our capture and storage cost over any previous HD format.? The XDCAM camcorders will help to bring our production capabilities to a new level that will be a great asset to our Olympics coverage.”
The new XDCAM HD models include the PDW-700 2/3-inch CCD camcorder and the PDW-HD1500 recording deck, as well as the dual-layer 50GB version of Sony’s optical Professional Disc(TM) media, model PFD50DLA. Also working closely with NBC is Sony’s Professional Services group, which is involved in product set-up and workflow testing, providing 100 percent uptime for all broadcasting equipment and operations


– One dayUS$ 0

HS-410

[Specification]
– SDI INPUT x 8ch / DVI-D INPUT x 1ch
– SDI OUTPUT x 5ch / DVI-D OUTPUT x 1ch
– Built-in Multi-Viewer with audio-level meter and a clock
– Super-clean chroma keyer employing Primatte®
algorithms – Support 3G SDI(1080/59.94p,1080/50p)
– Clip Store (20sec)
– 3D Support
– Intuitive user interface with wide color LCD
– Direct Control of Panasonic pan/tilt/zoom cameras via ether port.




SONY DFS-700A

[Description] SDI
BNC × 4 (BKDF-701장착시 BNC x8)
270Mb/s SMPTE-259M

Component
BNC (Y/R-Y/B-Y) ×4 (BKDF-701장착시 x8)
Y: 1.0Vp-p 75ohm, R-Y/B-Y: 0.756Vp-p 75ohm

RGB
BNC (RGB)×1 (Component와 절체)
R/G/B:0.756Vp-p 75ohm (SYNC ON GREEN)

Composite (BKDF-702장착시)
BNC x4 VIDEO: 1.0Vp-p 75ohm

S-Video (BKDF-702장착시)
DIN ×4 Y: 1.0Vp-p 75ohm, C: 0.286Vp-p 75ohm

DSK KEY IN
BNC ×2 loop-through, 1.0Vp-p 75ohm

REF VIDEO
BNC ×2 loop-through SYNC: 0.286Vp-p, BURST: 0.286Vp-p

Signal Outputs

SDI
BNC ×2 270Mb/s SMPTE-259M

Component
BNC (Y/R-Y/B-Y)×2
Y: 1.0Vp-p 75ohm, R-Y/B-Y: 0.756Vp-p 75ohm

Composite




0

PDW-700

[Specification]
NBC is planning to use the new XDCAM HD camcorder as its primary ENG camcorder for the Games. Crews will use the camcorders to record athlete arrivals, interviews, venue press conferences and any other assignment that requires portable recording and capture. The XDCAM HD decks will be the primary recording device, used for the “ingest wall” at the IBC. Telemundo, NBC Universal’s Spanish-language television network, will use the PDW-700 camcorders at its stand-up location overlooking the Olympic Stadium




SONY PMW-500

[Specification]
HD422 50 Mode: MPEG-2 422P@HL, 50 Mbps/CBR
1920 × 1080/59.94i, 50i, 29.97P, 25P,23.98P
1280 × 720/59.94P, 50P, 29.97P, 25P, 23.98P

HD 420 HQ Mode: MPEG-2 MP@HL, 35 Mbps/VBR
1440 × 1080/59.94i, 50i, 29.97P, 25P,23.98P
1280 × 720/59.94P, 50P, 23.98P(PD)

SD IMX Mode (with optional CBK-MD01):
720 × 486/59.94i, 29.97PsF
720 × 576/50i, 25PsF

SD DVCAM Mode (with optional CBK-MD01):
720 × 480/59.94i, 29.97PsF
720 × 576/50i, 25PsF
FAT Mode
HD HQ 1920 Mode: MPEG-2 MP@HL, 35 Mbps/VBR
1920 × 1080/59.94i, 50i, 29.97P, 25P,23.98P

HD HQ 1440 Mode: MPEG-2 MP@HL, 35 Mbps/VBR
1440 × 1080/59.94i, 50i, 29.97P, 25P,23.98P

HD HQ 1280 Mode: MPEG-2 MP@HL, 35 Mbps/VBR
1280 × 720/59.94P, 50P, 29.97P, 25P,23.98P

HD SP 1440 Mode: MPEG-2 MP@H-14, 25 Mbps/CBR
1440 × 1080 /59.94i, 50i
(23.98P is converted to 59.94i in 2-3 pulldown processing)

SD DVCAM Mode (with optional CBK-MD01):
720 × 480/59.94i, 29.97PsF
720 × 576/50i, 25PsF


SONY DXC-D50 / DSR-450

[Specification]

Power requirements DC 12V
Power consumption Approx. 17 W (with DC 12V power, REC mode, viewfinder off, LCD monitor off)
Mass Approx. 6.5 kg (14 lb 5 oz) (with viewfinder, microphone, BP-GL65 battery, Mini DVCAM cassette, VCL-917BY lens)
Continuous operating time Approx. 300 min. (with BP-GL95 battery, REC mode)
Built-in LCD monitor 2.5-inch type colour (214,000 pixels)
Viewfinder 1.5-inch type CRT, monochrome

Inputs/Outputs
Analogue composite input BNC (with CBK-SC01)
Genlock video input BNC
Audio input (CH1/2) XLR-3 (x2), female
Microphone input XLR-3, female
Time Code input BNC
SDI output BNC (with CBK-SD01)
i.LINK output 6-pin, IEEE1394 based
Analogue composite output BNC
Audio output (CH1/2) RCA pin (x2)
Time Code output BNC
Monitor output BNC
Earphone output Mini jack
Lens 12-pin
VF 20-pin
Remote 8-pin
Wireless microphone 7-pin
Light 2-pin, DC 12V, max. 50W
DC input XLR 4-pin, male
DC output 4-pin (for wireless microphone receiver), DC 12V (max. 0.2A)

Camera Performance
Pickup device 3-chip 2/3-inch type Power HAD EX CCD
Aspect ratio 16:9/4:3 switchable




Umesh M16 (Outdoor Fixed LED Display)

[Specification]

Features
Complete AL frame design, ultra-thin & ultra-light
Hollow out design, high light transmittance
Easy installation and maintenance
Cabinet with no fan design, low noise, low power consumption
High gray grade、high refresh rate、high brightness
IP65(front), high protection level
Cabinet and module front/rear maintenance can be realized

Parameter
Pixel Pitch : 16.6mm
Pixel configuration :1R1G1B
LED type : DIP346
Brightness : 5500 cd/m²
Color temperature : 6500K
Viewing angle : H: 110°; V:50°
Pixel density :3600 pixels/m²
ecommended viewing distance : 17 M
Module size : 196mm×400mm
Cabinet size : W800mm×H800mm×D75mm
Weight : 15.5 kg/panel

Ustorm S10 (Outdoor Fixed LED Display)

[Specification]

Features
Completely sealed module design, All-weather & UV-resistant Outdoor LED display, guaranteed reliability under the toughest operation conditions
High reliability, excellent circuit design, no fans, lower power consumption
Easy to maintain, offering front and rear access for easy maintenance
Lightweight design with cabinet thickness of 100mm, weight of 31.25KG/SQM, these features help you save the cost of transportation as well as the cost of installation.
Cabinet size optional: 1200*1200mm or 800*800mm;

Utile R4 (Indoor Rental LED Display)

[Specification]
Features
Ultra-thin & ultra-light
Die casted AL cabinets, high precision with seamless splicing
Standard cabinet size: 500x500mm, convenient for area calculation
Highly effective & quick for transportation and screen assembling
SMD black light, wider viewing angle, high-contrast(5000:1),soft image
Special buckles structural connection between the cabinets,don’t need other tools
Cabinets are in common use for standard modules,shorten production cycl

Parameter
Pixel Pitch : 4.8mm
Pixel configuration : 1R1G1B
LED type : 3-in-1 SMD3528
Brightness : 1300cd/㎡
Color temperature : 6500K
Viewing angle : H: 120°; V:100°
Pixel density : 43264pixels/㎡
Recommended viewing distance : 4.8M
Module size : 250mm×250mm
Cabinet size : W500m×H500mm×D84mm
Weight : 8.5 kg/panel

V6 (Indoor Fixed LED Display

[Specification]

Features
Standard cabinet design
High reliability: Average time between failures(MTBF)is 2 years at least
Long life time: Normal lifespan should be more than 8 years
Energy saving: 51% energy saving, lowering operation cost significantly
Dot by dot calibration: With Unilumin’s pioneering calibration system, LED display keeps stunning image even after years’s using
Easy to install: Stacking installation design enables easier installation

Parameter
Pixel Pitch : 6mm
Pixel configuration : 1R1G1B
LED type : 3-in-1 SMD3528
Brightness : 800 cd/㎡
Color temperature : 6500K
Viewing angle : H: 120°; V:100°
Physical density : 27778 pixels/㎡
Recommended viewing distance : 6 M
Module size : 192mm×192mm
Cabinet size : W768m×H768mm×D120mm
Weight : 22 kg

UTV1.6(1.6mm LED display)

[Specification]
Features

Extremely high pixel density;
Black LED, phenomenal contrast ratio of 5000:1;
Aluminum cabinet design, light weight and high precision;
Vibrant images with uniform colors;
Extra wide viewing angle.

Parameter
Pixel Pitch
1.667mm
Pixel configuration
1R1G1B
LED type
3-in-1 SMD1010
Brightness
800 cd/m²
Color temperature
6500K
Viewing angle
H: 160°; V:160°
Pixel density
360000 pixels/m²
Recommended viewing distance
≥1.7M
Module size
240mm×240mm
Cabinet size
W480mm×H480mm×D86mm
Weight
11kg/panel

UTV2.5 (2.5mm LED display)

[Specification]
– Features
Extremely high pixel density
Black LED, phenomenal contrast ratio of 5000:1
Aluminum cabinet design, light weight and high precision;
Vibrant images with uniform colors;
Extra wide viewing angle

Parameter
Pixel Pitch
2.5mm
Pixel configuration
1R1G1B
LED type
3-in-1 SMD2121
Brightness
800 cd/m²
Color temperature
6500K
Viewing angle
H: 160°; V:160°
Pixel density
160000 pixels/m²
Recommended viewing distance
≥2.5 M
Module size
160mm×160mm
Cabinet size
W480mm×H480mm×D90mm
Weight
10.5 kg/panel


WinVision 9mm

[Specification]
– Product Weight: 19 lbs with standard factory frame
– Dimensions: 23.6″W x 23.6″H x 4.9″D
– LED Type: 3-in-1 SMD
– Pixel Pitch: 9.375mm
– Number of Pixels: 64 x 64 (4,096) per tile
– Pixel Density: 11,377 pixels/m2
– Brightness: 3300 NITS
– Colors: 281 trillion
– Refresh Rate: 240Hz
– Viewing Angle
– Vertical: 120°
– Horizontal: 120°
– Transparency: 30%
– Lifetime: 50,000 hours
– Dimensions: 23.6″W x 23.6″H x 4.9″D (600 x 600 x 125 – mm)
– Weight: 19 lbs (8.9 kg) with standard factory frame
– AC Power In: 100-240V
– Power Consumption (w/unit): 400W max per tile


Multi PDP



[Specification]

DZF (DEAD ZONE FREE) using a technique
PDP interval 4MM below
There is no distortion of the screen provides a very large screen
PC, DVI, COMPOSITE, COMPONENT
Simultaneously implement a variety of sources and MSCS
(MULTI SCREEN CONTORL SYSTEM)
Be configured to suit the needs of consumers by using
Is
The 1.000CD / M of brightness and 10,000:1 CONTRAST
RATIO level of response rate, close to natural
Boasts the highest image quality, color reproduction

LED BAR (UAL-030)

[Specification]

Reflector patterns available in spot, flood, combination or bat beaming
1. 50,000+hours average lifespan
2,5years of continuous use
3. 96% optical/reflector efficiency
4. 9-36 Volt DC Input
5,100%optically clear
6. GE LEXAN lens
7,Instant on/off, no warm-up
8. Operating Temp: -40 ~ + 155 deg
9,Dual-oversized heat sink
10,Low power consumption
11,IP68 Rating
12,Military standard breather
13,Unique Durable Mar/UV resistant paiting technology
14,Sealed waterproo connector
15,Pass Chinese Military Standard GJB 150&US MIL810-STD
16,High Temperature, Low Temperature, Temperature shock, UV, Humidity, Salt Fog, Sand and Dust, Vibration, Altitude, CE&Rohs certification
17.Usage: ATV, SUV, Project vehicle, off road , 4×4 ,mining vehicle , heavy equipments Truck, Jeep, Motorcycle, Boat etc


Robe575at Spot

[Specification]
Robe ColorSpot 575 AT with 2 colour wheels one with 9 dichroic filters plus open, the other with 8 replaceable dichroic filters plus open. Slot & Lock system for easy gobo changing. 2 gobo wheels one with 9 static replaceable gobos plus open, the other with 7 rotating replaceable gobos plus open, varispeed and variable direction prism, Multistep zoom, remote focus, Variable frost effect, Motorised iris, Full range dimming and variable strobe effect, Master/slave option, Stand alone option




PAR46

[Specification]
– Rugged sheet steel construction
– Hinged rear cover for easy lamp access
– 360° lamp rotation
– Spring loaded accessory holder safety latch
– Medium side prong socket
– Three 36″ Teflon lead wires
– Available with HPL or G9.5 lamp
– Color frame and safety cable with spring clip included
– U.L. and c.U.L. listed for 200 watts


Par Light 64

[Specification]
– Constructed of rugged sheet steel (PAR56, PAR64) or rolled air- craft aluminum (PAR64-AL)- Three 36′′ Teflon® lead wires
– Available with HPL or G9.5 lamp
– Color frame, wire mesh safety screen, and safety cable with spring clip included
– U.L.- and c.U.L.-listed for 500 watts (PAR56) or 1000 watts (PAR64 and PAR64-AL)


750w source4 etc

[Specification]
– 5º, 10º, 14º, 19º, 26º, 36º, 50º, 70º and 90º field angles
– Rated up to 750W
– Super-efficient HPL lamp
– Faceted dichroic reflector removes 90% of IR heat from beam
– Interchangeable lens tubes
– Rotating barrel ± 25º
– Three-plane stainless-steel shutter blade assembly
– Tool-free lamp adjustment
– Insulated rear handle
– Rugged die-cast aluminum construction
– Supports Dimmer Doubling™ (North America only)


pearl 2010

[Specification]
Internal Flash Drive, similar in functionality to a hard disk but faster and more rugged. Provides enough storage for:- The entire Fixture Library of more than 3,000 files
Over a hundred show files.
Removable external Memory Stick.

Cache the entire Fixture library of more than 3,000 files
Improved method of Fixture selection for Patching
New Locate Fixture button
Fixture Selects (selecting the top row of faders)
2048 Channels.
240 Intelligent Fixtures.
240 Dimmer Control Channels.
Theatrical Plotting and Playback functions.
Shape Generator for instant creation of patterns and effects.
15 Playback Masters controlling 450 memories, chases or cue lists.
MIDI and Bass, Mid, Treble sound to light triggers.
Colour VGA output fitted as standard.
Front panel now reverse printed Poly Carbonate Laminate using technology from the Diamond 4, this is incredibly hard wearing and looks excellent.
Each console individually has an electronic serial number, linked to physically engraved metalwork numbering making reselling of stolen consoles more difficult.
Supplied with PC applications: Avolites Visualiser, Pearl Simulation program and Cache Builder.


0

MA2 ON PC

[Specification]
The grandMA2 ultra-light features the full network performance of the grandMA2 series. All controls are at the same place as on the on bigger consoles.
With its 4,096 parameters and 6 DMX outputs the grandMA2 ultra-light is the perfect backup solution too. It brings all the features of the ‘series 2’ consoles to smaller shows and budgets, including intuitive and fast control of all lighting genres and the handling of an almost infinite number of presets, cues, pages, sequences and effects.


Power LED par64

[Specification]
– 5º, 10º, 14º, 19º, 26º, 36º, 50º, 70º and 90º field angles
– Rated up to 750W
– Super-efficient HPL lamp
– Faceted dichroic reflector removes 90% of IR heat from beam
– Interchangeable lens tubes
– Rotating barrel ± 25º
– Three-plane stainless-steel shutter blade assembly
– Tool-free lamp adjustment
– Insulated rear handle
– Rugged die-cast aluminum construction
– Supports Dimmer Doubling™ (North America only)


pearl 2008

[Specification] Internal Flash Drive, similar in functionality to a hard disk but faster and more rugged. Provides enough storage for:- The entire Fixture Library of more than 3,000 files
Over a hundred show files.
Removable external Memory Stick.

Cache the entire Fixture library of more than 3,000 files
Improved method of Fixture selection for Patching
New Locate Fixture button
Fixture Selects (selecting the top row of faders)
2048 Channels.
240 Intelligent Fixtures.
240 Dimmer Control Channels.
Theatrical Plotting and Playback functions.
Shape Generator for instant creation of patterns and effects.
15 Playback Masters controlling 450 memories, chases or cue lists.
MIDI and Bass, Mid, Treble sound to light triggers.
Colour VGA output fitted as standard.
Front panel now reverse printed Poly Carbonate Laminate using technology from the Diamond 4, this is incredibly hard wearing and looks excellent.
Each console individually has an electronic serial number, linked to physically engraved metalwork numbering making reselling of stolen consoles more difficult.
Supplied with PC applications: Avolites Visualiser, Pearl Simulation program and Cache Builder.


TURBOSOUND TXD-252

[Specification]

* DIMENSIONS (HxWxD) 1220mm x 540mm x 434mm (48” x 21.3” x 17.1”)
* NET WEIGHT 49kg (107.8lbs)
* COMPONENTS 2 x 15” (381mm) LF drivers, 1 x 3” voice coil HF compression driver
* FREQUENCY RESPONSE 44Hz – 17kHz ±4dB
* NOMINAL DISPERSION 80°H x 50°V rotatable waveguide allows swap of horizontal and vertical pattern
* POWER HANDLING passive: 1000 watts r.m.s., 2000 watts program
* Recommended amplifier power 2000 watts @ 4 ohms
* bi-amp: LF 1000 watts r.m.s., 2000 watts program @ 4 ohms;
* HF 160 watts r.m.s., 320 watts program @ 8 ohms
* SENSITIVITY 97dB, 1 watt @ 1 metre
* CALC. MAXIMUM SPL 127dB continuous, 133dB peak
* CROSSOVER Passive: 12dB/octave high-pass and low-pass at 1kHz
* Active: 24dB/octave Linkwitz-Riley @ 1kHz
* NOMINAL IMPEDANCE 4 ohms passive; HF: 8 ohms, LF: 4 ohms (biamped mode)
* CONSTRUCTION 15mm (5/8”) birch plywood enclosure. Finished in TurboBlue™ semi-matt textured paint
* (optional black textured paint). Six recessed carrying handles. Pre-drilled for T4 wheels.
* GRILLE Heavy duty powder coated perforated steel mesh
* CONNECTORS Passive mode: (2) Neutrik Speakon NL4MP, wired pin1+: positive, pin1-: negative, pins2+ and
* 2- N/C. Biamped mode: (1) Neutrik Speakon NL-4MDVS, wired pin1+: LF positive, pin1-: LF
* negative, pin2+: HF positive, pin2-: HF negative
