[Specification]

Frequency Response 50~17,000 Hz
Polar Pattern Cardioid / SuperCardioid / Omnidirectional
Output Impedance (at 1,000 Hz) Rated at 150 Ω (180 Ω actual)
Open Circuit Sensitivity 1kHz일 때, ref. 1 V per Pascal*
Cardioid : -33.5dBV (21.1mV)
Supercardioid : -32.5dBV (23.7mV)
Omnidirectional : -28.0dBV (39.8mV)
* 1 Pascal=94 dB SPL
Maximum SPL (1kHz at 1% THD, 1 kΩ load)
Cardioid: 123.0 dB
Supercardioid: 122.0 dB
Omnidirectional: 117.5 dB
Equivalent Output Noise (A-weighted)
Cardioid: 29.0 dB SPL
Supercardioid: 28.0 dB SPL
Omnidirectional: 70.5 dB SPL
Signal to Noise Ratio (referenced at 94 dB SPL)
Cardioid: 65.0 dB
Supercardioid: 66.0 dB
Omnidirectional: 70.5 dB
Dynamic Range with 1 kΩ load 94.0 dB
Common Mode Rejection 45.0 dB minimum
Mute Switch Attenuation 50.0 dB minimum
Preamplifier Output Clipping Level (1% THD) -6.0 dBV (0.5 V)
Power Requirements 11 to 52 Vdc phantom, 2.0 mA
Weight 0.82 kg net, 1.64 kg packaged
